Fujifilm X-T20


Fujifilm X-T20 front

Portability
83
Imaging
70
Features
82
Overall
74

Fujifilm X-T20 overview

Fujifilm X-T20 is FujiFilm's Entry-Level Mirrorless camera initially released on January of 2017. It features a 24 MegaPixel, CMOS X-TRANS III APS-C size sensor with a peak resolution of 6000 x 4000.

FujiFilm released this camera in order to upgrade the previous Fujifilm X-T10 (Read Full Comparison) & afterwards released the updated Fujifilm X-T30 (Read Full Comparison) as a way to upgrade this model.

The Fujifilm X-T20 comes in at #14 out of 111 in Entry-Level Mirrorless cameras & all around #100 out of 1428 for cameras in our database. You can try out our Smart camera finder to find camera rankings based on your personal requirements.

Last day to get your files as Canon Irisa shuts down

Below is a chart of multiple criteria used in the scoring system.

Fujifilm X-T20 family

The Fujifilm X-T20 is part of a family of products. You can view the detailed list underneath.

ModelVisualizeResolutionSensor SizeMax fpsReleased
Unsplash partners with Institutions to bring historical archive photos 400 Megapixel mode coming to Fujifilm GFX 100

Fujifilm X-T20 Pros and Cons

Here is a shortlist of advantages and disadvantages of the Fujifilm X-T20 based on features which are typically seen as crucial in a camera.

comes with face detect focusing
comes with phase detect AF
comes with touch focus
comes with tracking focus
does have HDMI support
does have microphone jack
doesnt have low pass filter
exports RAW files
flash built-in
good resolution screen (920 thousand dot)
has a tilting screen
high quality video (3840 x 2160 resolution)
MP count good (24MP)
nice screen size (3 inch)
quiet shutter (1/32,000 seconds)
sensor size is decent (APS-C)
switch lenses (Fujifilm X mount)
touchscreen
you can focus manually
display isn't selfie friendly
no headphone jack
no image stabilization
World's smallest camera makes it into Guinness Book of Records

Fujifilm X-T20 Sensor information

The Fujifilm X-T20 is powered by the X-Processor Pro2 processor. The dimension of the sensor in the Fujifilm X-T20 is 23.6mm x 15.6mm (APS-C). The 368 mm² sensor is able to resolve 6000 x 4000 pixels with aspect ratios of 1:1, 3:2 and 16:9.

Handle those 8K RED files like a boss

The CMOS X-TRANS III sensor has 24MP and includes a native ISO range of 200 - 12800. The ISO can be widened electronically to 100 - 51200. RAW photos are saved which means that you have more margin for error.

FujiFilm chose to omit the low pass filter for the Fujifilm X-T20. This may result in more clear photos but may create moire in some circumstances.

The picture underneath illustrates the Fujifilm X-T20's sensor size compared to other common sizes. The Fujifilm X-T20 sensor has a crop factor of 1.5 and is presented in green.

Fujifilm X-T20 sensor size Instagram's $20 billion Ad success

To get a sense of various aspect ratios, you can refer to the visual below.

Camera sensor aspect ratios

Fujifilm X-T20 dimensions

Fujifilm X-T20 weighs about 0.84 lb (383g / 13.51 oz) & the overall size of the camera is 118mm x 83mm x 41mm (4.6" x 3.3" x 1.6"). The weight of general Entry-Level Mirrorless camera is 325g so the Fujifilm X-T20 is heavier than other competitors.

Photographer fined '$200,000' for failing to deliver photos

Underneath is a shot of the Fujifilm X-T20 next to a softdrink so you can get a feel for its size.

Fujifilm X-T20 dimensions scale

The top view just below will show you the button arrangement on the Fujifilm X-T20.

Fujifilm X-T20 topview buttons dials

Fujifilm X-T20 Lens information

The Fujifilm X-T20 fits the Fujifilm X mount and has 55 lenses currently available. Here is some of the lenses we have in our database that will fit the Fujifilm X-T20.

ModelVisualizeFocal LengthApertureStabilizedWeight
Zeiss-Touit-2.850M-Fujifilm-X lensZeiss Touit 2.850M50mmf/2.8 290g
Lensbaby-Velvet-56-Fujifilm-X lensLensbaby Velvet 5656mmf/1.6 400g
Google will print your 'Best' photos for $8 a month
Samyang-10mm-f2.8-ED-AS-NCS-CS-Fujifilm-X lensSamyang 10mm f2.8 ED AS NCS CS10mmf/2.8 580g
Samyang-20mm-F1.8-ED-AS-UMC-Fujifilm-X lensSamyang 20mm F1.8 ED AS UMC20mmf/1.8497g
Venus-Laowa-9mm-F2.8-Zero-D-Fujifilm-X lensVenus Laowa 9mm F2.8 Zero-D9mmf/2.8215g
Fujifilm-XF-16-80mm-F4-R-OIS-WR lensFujifilm XF 16-80mm F4 R OIS WR16-80mmf/4 440g
Handle those 8K RED files like a boss
Samyang-16mm-f2.0-ED-AS-UMC-CS-Fujifilm-X lensSamyang 16mm f2.0 ED AS UMC CS16mmf/2.0 583g
Last day to get your files as Canon Irisa shuts down

Fujifilm X-T20 Connectivity

The Fujifilm X-T20 has the following connectivity:

  • USB Yes
  • Wireless Yes
  • HDMI Yes
  • GPS Yes

Cameras with NFC and Bluetooth support can easily be used wirelessly by smartphones. You can easily transfer photos and at times change settings without connecting physically with the camera.

A few apps also stream a Liveview and press the shutter whenever you aren't close to the camera. If the camera comes with a HDMI port, it could be hooked up to an external display. A good number of cameras enable you to charge the battery through the USB socket.

Unsplash partners with Institutions to bring historical archive photos

Fujifilm X-T20 Video information

The highest video resolution in the Fujifilm X-T20 is 3840 x 2160 and you can save in MPEG-4 and H.264 format. 2160p provides a fantastic resolution for video recording. You are able to downsample to Full HD in order to get cleaner results. Be wary of the substantial file sizes and make sure you own decent SD cards with good write speed. While the body contains a microphone port, it is unfortunately lacking a headphone port which means that you won't have the ability to check your audio levels.

400 Megapixel mode coming to Fujifilm GFX 100

Fujifilm X-T20 Weather Sealing

Fujifilm X-T20 doesn't have weather proofing so rainy conditions may affect the camera.

Fujifilm X-T20 Display and Viewfinder

The Fujifilm X-T20 features a 3 inch tilting display with a resolution of 920 thousand dots.

Moreover the display is touch friendly which means that you are able to shift focus points plus adjust settings using your finger.

Fujifilm X-T20 screen and viewfinder Control Profoto B10 & B10 Plus with your Android Phone

The View Finder details for Fujifilm X-T20 are below:

  • ViewFinder Electronic
  • Resolution 2,360 thousand dots
  • Coverage 100%
  • Magnification 0.62x

For sunny outdoor situations that make the camera screens washed out and difficult to see, viewfinders can be pretty helpful.

Fujifilm X-T20 Shutter information

Fujifilm X-T20 continuous shooting rate is 14.0 frames per second. The maximum shutter speed is 1/4000 seconds. The camera also offers silent electronic shutter of 1/32000 seconds. Keep in mind that the electronic shutter might result in "rolling shutter" in some circumstances.

Coronavirus is affecting the sensor business

Fujifilm X-T20 Flash and Hot shoe information

Fujifilm X-T20 comes with both inbuilt flash along with external flash ability. The highest flash sync is 1/180 seconds.

Fujifilm X-T20 Autofocus information

Fujifilm X-T20 comes with both Phase Detect AF plus Contrast Detect AF. Phase Detection autofocusing is more faster & exact than Contrast Detect autofocusing. The camera features Face detect which makes it helpful for people photography.

It features 325 focus points to choose from. Fujifilm X-T20 has tap to focus. You are able to use your fingers in order to shift focus. It also includes Tracking AF for things that move. Fujifilm X-T20 has manual focus if required in low light occasions or you need to have more exact focus control.

World's smallest camera makes it into Guinness Book of Records

Fujifilm X-T20 Battery life

The battery power (NP-W126S) on the Fujifilm X-T20 is designed to last for 350 clicks based on the CIPA specifications which is comparable with it's competition. The typical Entry-Level Mirrorless camera battery life is 338. Samsung NX mini features the highest (650) battery life in this class of cameras.

Following is a collection of Entry-Level Mirrorless cameras that have the highest battery life:

Fujifilm X-T20 for specific forms of photography

The following illustration gives a overview of the Fujifilm X-T20 for specific forms of photography. To see more, have a look at the specific section underneath.

Fujifilm X-T20 as a Portrait photography camera

The Fujifilm X-T20 has a points total of 82 which is wonderful, and means the camera is a awesome choice to use for portrait images. Photographing portrait images favors greatly towards sensor dimensions, support for RAW files plus the capability to use off-camera lighting.

Photographer fined '$200,000' for failing to deliver photos
focusing manually
decent MP (24MP)
decent sensor size (APS-C)
includes face detection focus
delivers RAW files

Fujifilm X-T20 as a Street photography camera

Having a terrific score of 79, the Fujifilm X-T20 is a terrific fit to use in street photography. A decent street photography camera has a perfect balance of image quality plus portability.

Google will print your 'Best' photos for $8 a month
has a tilting screen
sensor size is decent (APS-C)
delivers RAW files
comes with touch focus
lack of image stabilization

Sports photography with Fujifilm X-T20

A superb sports photography points total of 76 means the Fujifilm X-T20 is a terrific choice for taking photos of sports. A camera really should have good tracking and fast continuous shooting for sports photography.

Handle those 8K RED files like a boss
silent shooting (1/32,000 seconds)
sensor resolution is decent (24MP)
sensor size is good (APS-C)
supports tracking focus
supports phase detect autofocus
no image stabilization

Fujifilm X-T20 Travel photography info

Portability is pretty crucial when getting a camera for travel. All round, the Fujifilm X-T20 gets a very high 77 as a travel camera which is a terrific pick to take on your trips.

Last day to get your files as Canon Irisa shuts down
comes with focus by touch
decent sensor resolution (24MP)
flash built-in
screen is not selfie friendly

Fujifilm X-T20 Landscape photography information

For anybody who is planning to purchase a digital camera for landscape pictures, the most vital factor will no doubt be image quality. The Fujifilm X-T20 and it's fantastic rating of 80 as a landscape camera is a fantastic choice among it's rivals.

Unsplash partners with Institutions to bring historical archive photos
has manual focus
swap lenses (Fujifilm X mount)
nice screen size (3 inches)
decent MP (24 megapixels)
decent sensor size (APS-C)
does not have anti-alias filter
saves RAW formats
no image stabilization

Fujifilm X-T20 Vlogging info

A camera for vlogging should have a articulating display screen, microphone port and if possible image stabilization. Taking all things into account, the Fujifilm X-T20 is simply not good for vlogging as it receives a dreadful score of 36.

400 Megapixel mode coming to Fujifilm GFX 100
touchscreen functionality
comes with face detect autofocus
high res video (3840 x 2160 resolution)
does have microphone port
display is not selfie friendly
does not have image stabilization

Fujifilm X-T20 Alternatives

If you are shopping for alternatives to the Fujifilm X-T20, here is a range of the highest ranked cameras that fall into the class of Entry-Level Mirrorless.

The graph down below shows you an overview of the Fujifilm X-T20 compared to it's top ranked rivals mentioned previously.

There are more cameras you may view as alternatives. To go through a full comparison, click the "compare" link.

Control Profoto B10 & B10 Plus with your Android Phone

Specifications

General Information
Make
FujiFilm
Model
Fujifilm X-T20
Type
Entry-Level Mirrorless
Revealed
2017-01-18
Body design
SLR-style mirrorless
Sensor Information
Sensor type
CMOS X-TRANS III
Processor Chip
X-Processor Pro2
Sensor size
APS-C
Sensor measurements
23.6 x 15.6mm
Sensor area
368.2mm²
Sensor resolution
24 megapixels
Anti aliasing filter
Aspect ratio
1:1, 3:2 and 16:9
Highest resolution
6000 x 4000
RAW files
Highest native ISO
12800
Highest boosted ISO
51200
Lowest native ISO
200
Lowest boosted ISO
100
Autofocusing
Manual focus
Autofocus touch
Continuous autofocus
Single autofocus
Autofocus tracking
Selective autofocus
Center weighted autofocus
Autofocus multi area
Autofocus live view
Face detect focus
Contract detect focus
Phase detect focus
Number of focus points
325
Lens
Lens mounting type
Fujifilm X
Total lenses
54
Focal length multiplier
1.5
Screen
Range of display
Tilting
Display diagonal
3 inch
Resolution of display
920 thousand dot
Selfie friendly
Liveview
Touch friendly
Viewfinder Information
Viewfinder
Electronic
Viewfinder resolution
2,360 thousand dot
Viewfinder coverage
100%
Viewfinder magnification
0.62x
DXO scores
DXO All around score
not tested
DXO Color Depth score
not tested
DXO Dynamic range score
not tested
DXO Low light score
not tested
Features
Lowest shutter speed
30s
Highest shutter speed
1/4000s
Highest quiet shutter speed
1/32000s
Continuous shooting speed
14.0 frames per second
Shutter priority
Aperture priority
Manual exposure
Exposure compensation
Yes
Custom white balance
Image stabilization
Integrated flash
Flash range
5.00 m (ISO 100)
Flash options
Auto, forced flash, slow synchro, flash off, rear-curtain synchro, commander
Hot shoe
AEB
White balance bracketing
Highest flash sync
1/180s
Exposure
Multisegment exposure
Average exposure
Spot exposure
Partial exposure
AF area exposure
Center weighted exposure
Video features
Supported video resolutions
3840 x 2160 (29.97p, 25p, 24p, 23.98p), 1920 x 1080 (59.94p, 50p, 29.97p, 25p, 24p, 23.98p), 1280 x 720 (60p, 50p, 30p, 25p, 24p)
Highest video resolution
3840x2160
Video format
MPEG-4, H.264
Microphone input
Headphone input
Connectivity
Wireless
Built-In
Bluetooth
NFC
HDMI
USB
USB 2.0 (480 Mbit/sec)
GPS
Optional
Physical
Environmental seal
Water proof
Dust proof
Shock proof
Crush proof
Freeze proof
Weight
383g (0.84 pounds)
Dimensions
118 x 83 x 41mm (4.6" x 3.3" x 1.6")
Other
Battery life
350 images
Form of battery
Battery Pack
Battery model
NP-W126S
Self timer
Yes (10sec. / 2sec. Delay)
Time lapse shooting
Storage media
SD / SDHC / SDXC (UHS-II compatible)
Storage slots
1
Price at launch
$900
